    15A 600V Ultra Fast Recovery Rectifier Diode MUR1560 Single Leg Tube Packing

    Ask Lasest Price
    Brand Name : trusTec
    Model Number : MUR1560
    Certification : ROHS
    Price : Negotiable (EXW/FOB/CNF)
    Payment Terms : T/T
    Supply Ability : 800KK PCS per month
    Delivery Time : 10 work days fresh products
    • Product Details
    • Company Profile

    15A 600V Ultra Fast Recovery Rectifier Diode MUR1560 Single Leg Tube Packing

    15A 600V Ultra Fast Recovery Rectifier Diode MUR1560 Single Leg Tube Packing

    DIMENSIONS

    Symbol

    Test Conditions

    Maximum Ratings
    MUR1520MUR1540MUR1560Unit
    IFRMS IFAVM

    TVJ=TVJM

    TC=115oC; rectangular, d=0.5

    22

    15

    22

    15

    22

    15


    A

    IFRMtp<10us; rep. rating, pulse width limited by TVJM170170170

    IFSM

    TVJ=45oC t=10ms (50Hz), sine t=8.3ms (60Hz), sine

    250

    270

    230

    250

    210

    230


    A

    TVJ=150 C t=10ms(50Hz), sine190170150
    t=8.3ms(60Hz), sine210190170
    TVJ=45oC t=10ms (50Hz), sine t=8.3ms (60Hz), sine505050
    I2t505050A2s
    TVJ=150 C t=10ms(50Hz), sine363636
    t=8.3ms(60Hz), sine373737
    TVJ TVJM

    -40...+150

    150


    oC

    Tstg-40...+150
    PtotTC=25oC80W
    MdMounting torque0.4...0.6Nm
    Weight2g

    Symbol

    Test Conditions

    Characteristic Values
    MUR1520MUR1540MUR1560Unit
    IRTVJ=25oC; VR=VRRM TVJ=25oC; VR=0.8.VRRM TVJ=125oC; VR=0.8.VRRM

    20

    10

    1.5

    20

    10

    1.5

    20

    10

    1.5

    uA

    uA

    mA

    VF

    IF=16A; TVJ =150oC

    TVJ=25oC

    1.0

    1.2

    1.2

    1.4

    1.3

    1.6

    V
    VTOFor power-loss calculations only0.780.850.98V
    rTTVJ=TVJM25.527.828.7m
    RthJC2.5
    RthCK0.5K/W
    RthJA60
    trrIF=1A; -di/dt=50A/us; VR=30V; TVJ=25oC35ns
    IRMVR=350V; IF=8A; -diF/dt=64A/us; L<_0.05uH; TVJ=100oC2.8A

    FEATURES
    International standard package JEDEC TO-220AC
    Planar passivated chips
    Very short recovery time
    Extremely low switching losses
    Low IRM-values
    APPLICATIONS
    Antiparallel diode for high frequency switching devices
    Antisaturation diode
    Snubber diode
    Free wheeling diode in converters and motor control circuits
    Rectifiers in switch mode power supplies (SMPS)
    Inductive heating and melting
    Uninterruptible power supplies (UPS)
    Ultrasonic cleaners and welders
