Silicon Zener Diodes 91V 82V 87V 100V 110V 120V 130V 1N5375B 1N5376B 1N5377B 1N5378B 1N5379B 1N5380B 1N5381B

Ask Lasest Price
Brand Name :	trusTec
Model Number :	1N5375B
Certification :	ROHS
Price :	Negotiable (EXW/FOB/CNF)
Payment Terms :	T/T
Supply Ability :	800KK PCS per month
Delivery Time :	10 work days fresh products

Add to Cart

Product Details
Company Profile

Silicon Zener Diodes 91V 82V 87V 100V 110V 120V 130V 1N5375B 1N5376B 1N5377B 1N5378B 1N5379B 1N5380B 1N5381B

Silicon Diode Zener 5Watt 82V 87V 91V 100V 110V 120V 130V 1N5375B 1N5376B 1N5377B 1N5378B 1N5379B 1N5380B 1N5381B

1N5333B THRU 1N5388B

ZENER DIODES

Zener Voltage - 3.3 to 200 Volts Peak Pulse Power - 5.0W

RoHS COMPLIANT

Plastic Silicon Zener Diode 5W 3.3V 1N5333B 1N5334B 1N5335B 1N5336B 1N5337B 1N5338B 0

FEATURES

The plastic package carries Underwriters Laboratory

Flammability Classification 94V-0

Low Zener Impedance

Low Reverse Leakage

High Stability and High Reliablity

MECHANICAL DATA

Case: JEDEC DO-201AD molded plastic body

Terminals: Plated axial leads, solderable per MIL-STD-750,

Method 2026

Polarity: Color band denotes cathode end

Mounting Position: Any

Weight:0.04 ounce, 1.10 grams

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Parameters	Symbol	Value	Unit
Power Dissipation	Pd	5 1)	W
Operating junction temperature	Tj	-65~+150	℃
Storage temperature range	Tstg	-65~+150	℃

Ratings at 25 C ambient temperature unless otherwise specified.

1) Valid provided that leads are kept at ambient temperature at a distance of 8mm from case

ELECTRICAL CHARACTERISTICS

TYPE NO	VZ(V)		ZZT(Ω)		ZZK(Ω)		IR(uA)		IFSM	IZM
TYPE NO	Nom.	IZT(mA)	MAX	IZT(mA)	MAX	IZK(mA)	MAX	VR(V)	A	mA
1N5333B	3.3	380	3	380	400	1	300	1	20	1440
1N5334B	3.6	350	2.5	350	500	1	150	1	18.7	1320
1N5335B	3.9	320	2	320	500	1	50	1	17.6	1220
1N5336B	4.3	290	2	290	500	1	10	1	16.4	1100
1N5337B	4.7	260	2	260	450	1	5	1	15.3	1010
1N5338B	5.1	240	1.5	240	400	1	1	1	14.4	930
1N5339B	5.6	220	1	220	400	1	1	2	13.4	865
1N5340B	6	200	1	200	300	1	1	3	12.7	790
1N5341B	6.2	200	1	200	200	1	1	3	12.4	765
1N5342B	6.8	175	1	175	200	1	10	5.2	11.5	700
1N5343B	7.5	175	1.5	175	200	1	10	5.7	10.7	630
1N5344B	8.2	150	1.5	150	200	1	10	6.2	10	580
1N5345B	8.7	150	2	150	200	1	10	6.6	9.5	545
1N5346B	9.1	150	2	150	150	1	7.5	6.9	9.2	520
1N5347B	10	125	2	125	125	1	5	7.6	8.6	475
1N5348B	11	125	2.5	125	125	1	5	8.4	8	430
1N5349B	12	100	2.5	100	125	1	2	9.1	7.5	395
1N5350B	13	100	2.5	100	100	1	1	9.9	7	365
1N5351B	14	100	2.5	100	75	1	1	10.6	6.7	340
1N5352B	15	75	2.5	75	75	1	1	11.5	6.3	315
1N5353B	16	75	2.5	75	75	1	1	12.2	6	295
1N5354B	17	70	2.5	70	75	1	0.5	12.9	5.8	280
1N5355B	18	65	2.5	65	75	1	0.5	13.7	5.5	265
1N5356B	19	65	3	65	75	1	0.5	14.4	5.3	250
1N5357B	20	65	3	65	75	1	0.5	15.2	5.1	237
1N5358B	22	50	3.5	50	75	1	0.5	16.7	4.7	216
1N5359B	24	50	3.5	50	100	1	0.5	18.2	4.4	198
1N5360B	25	50	4	50	110	1	0.5	19	4.3	190
1N5361B	27	50	5	50	120	1	0.5	20.6	4.1	176
1N5362B	28	50	6	50	130	1	0.5	21.2	3.9	170
1N5363B	30	40	8	40	140	1	0.5	22.8	3.7	158
1N5364B	33	40	10	40	150	1	0.5	25.1	3.5	144
1N5365B	36	30	11	30	160	1	0.5	27.4	3.3	132
1N5366B	39	30	14	30	170	1	0.5	29.7	3.1	122
1N5367B	43	30	20	30	190	1	0.5	32.7	2.8	110
1N5368B	47	25	25	25	210	1	0.5	35.8	2.7	100
1N5369B	51	25	27	25	230	1	0.5	38.8	2.5	93
1N5370B	56	20	35	20	280	1	0.5	42.6	2.3	86
1N5371B	60	20	40	20	350	1	0.5	42.5	2.2	79
1N5372B	62	20	42	20	400	1	0.5	47.1	2.1	76
1N5373B	68	20	44	20	500	1	0.5	51.7	2	70
1N5374B	75	20	45	20	620	1	0.5	56	1.9	63
1N5375B	82	15	65	15	720	1	0.5	62.2	1.8	58
1N5376B	87	15	75	15	760	1	0.5	66	1.7	54.5
1N5377B	91	15	75	15	760	1	0.5	69.2	1.6	52.5
1N5378B	100	12	90	12	800	1	0.5	76	1.5	47.5
1N5379B	110	12	125	12	1000	1	0.5	83.6	1.4	43
1N5380B	120	10	170	10	1150	1	0.5	91.2	1.3	39.5
1N5381B	130	10	190	10	1250	1	0.5	98.8	1.2	36.6
1N5382B	140	8	230	8	1500	1	0.5	106	1.2	34
1N5383B	150	8	330	8	1500	1	0.5	114	1.1	31.6
1N5384B	160	8	350	8	1650	1	0.5	122	1.1	29.4
1N5385B	170	8	380	8	1750	1	0.5	129	1.0	28
1N5386B	180	5	430	5	1750	1	0.5	137	1.0	26.4
1N5387B	190	5	450	5	1850	1	0.5	144	0.9	25
1N5388B	200	5	480	5	1850	1	0.5	152	0.9	23.6

RATINGS ANDCHARACTERISTICCURVES

Plastic Silicon Zener Diode 5W 3.3V 1N5333B 1N5334B 1N5335B 1N5336B 1N5337B 1N5338B 1

Plastic Silicon Zener Diode 5W 3.3V 1N5333B 1N5334B 1N5335B 1N5336B 1N5337B 1N5338B 2

Plastic Silicon Zener Diode 5W 3.3V 1N5333B 1N5334B 1N5335B 1N5336B 1N5337B 1N5338B 3

Plastic Silicon Zener Diode 5W 3.3V 1N5333B 1N5334B 1N5335B 1N5336B 1N5337B 1N5338B 4

Plastic Silicon Zener Diode 5W 3.3V 1N5333B 1N5334B 1N5335B 1N5336B 1N5337B 1N5338B 5

Plastic Silicon Zener Diode 5W 3.3V 1N5333B 1N5334B 1N5335B 1N5336B 1N5337B 1N5338B 6

Plastic Silicon Zener Diode 5W 3.3V 1N5333B 1N5334B 1N5335B 1N5336B 1N5337B 1N5338B 7

Plastic Silicon Zener Diode 5W 3.3V 1N5333B 1N5334B 1N5335B 1N5336B 1N5337B 1N5338B 8

Plastic Silicon Zener Diode 5W 3.3V 1N5333B 1N5334B 1N5335B 1N5336B 1N5337B 1N5338B 9
