    UF1M Us1m Ultra Fast Recovery Rectifier Diode 1000v 1A Smd Ultrafast Rectifier Diode

    Ask Lasest Price
    Brand Name : trusTec
    Model Number : US1M
    Certification : ROHS
    Price : Negotiable (EXW/FOB/CNF)
    Payment Terms : T/T
    Supply Ability : 800KK PCS per month
    Delivery Time : 10 work days fresh products
    • Product Details
    • Company Profile

    UF1M Us1m Ultra Fast Recovery Rectifier Diode 1000v 1A Smd Ultrafast Rectifier Diode

    1A 1000V Surface Mount Silicon SMD Ultra Fast Recovery Rectifier Diode US1M UF1M
    US1A THRU US1M
    SURFACE MOUNT ULTRA FAST RECTIFIERS
    Reverse Voltage - 50 to 1000 Volts Forward Current - 1.0 Ampere

    Product Size

    Technical Parameters


    Type

    VRRM

    V

    IAV

    A

    IFSM

    A

    VF

    V

    IR

    μA

    Trr

    ns

    US1A501301550
    US1B1001301550
    US1D2001301550
    US1G4001301.4550
    US1J6001301.7575
    US1K8001301.7575
    US1M10001301.7575

    Product Features


    The plastic package carries Underwriters Laboratory Flammability Classification 94V-0
    For surface mounted applications
    Ultra fast switching for high efficiency
    Low reverse leakage
    Built-in strain relief,ideal for automated placement
    High forward surge current capability
    High temperature soldering guaranteed 250℃/10 seconds at terminals
    Mechanical Data
    Case: JEDEC DO-214AC molded plastic body
    Terminals: Solder plated, solderable per MIL-STD-750, Method 2026
    Polarity: Color band denotes cathode end
    Mounting Position: Any
    Weight: 0.002 ounce, 0.07 grams
